| Nambari ya Sehemu | HSD103IPW1-A10-0299 |
| Chapa | HannStar |
| Ukubwa | 10.3 |
| Maombi | Automotive Display |
| Azimio | 1280×480 |
| Muundo | CELL, a-Si TFT-LCD |
| Mwangaza | |
| CR | 900:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | No |
| Kiolesura | |
| mtengenezaji | HannStar |
| jina la mfano | HSD103IPW1-A10-0299 |
| ukubwa wa skrini | 10.3 inch |
| aina ya skrini | CELL, a-Si TFT-LCD |
| nambari ya pixel | 1280(RGB)×480 (DVGA) 133PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 243.84 × 91.44 (H×V) |
| muhtasari(mm) | 253 × 103.3 × 1.25 (H×V×D) |
| eneo la bezel(mm) | - |
| matibabu | Antiglare, Hard coating (3H) |
| mwangaza | 0 cd/m² |
| uwiano wa utofautishaji | 900 : 1 (Typ.) (TM) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| majibu | 30 (Typ.)(Tr+Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | IPS Pro, Normally Black, Transmissive |
| unene wa kioo | 0.50+0.50 mm |
| uhamishaji | 4.7% (Typ.)(with Polarizer) |
| kina cha rangi | 262K/16.7M 70% NTSC |
| backlight | No B/L |
| wingi | TBD |
| kutumika kwa | Automotive Display |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| DJ103FA-01A | Innolux | 10.3 | 1920×720 |
