| Nambari ya Sehemu | HV104X01-100 |
| Chapa | HYDIS |
| Ukubwa | 10.4 |
| Maombi | GM |
| Azimio | 1024×768 |
| Muundo | LCM |
| Mwangaza | 350 |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | BOE HYDIS |
| mfano wa paneli | HV104X01-100 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.4 inch |
| azimio | 1024(RGB)×768 , XGA |
| hali ya kuonyesha | FFS, Normally Black, Transmissive |
| eneo la kazi | 210.4×157.8 mm |
| muhtasari | 237.8×178.3 mm |
| uso | Antiglare (Haze 25%), Hard coating (3H) |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193140% |
| wakati wa majibu | 40 (Typ.)(Tr+Td) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 2 pcsCCFLWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 6-bit), 14 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | GM |
