| Nambari ya Sehemu | HV320WHB-N5M |
| Chapa | BOE |
| Ukubwa | 32.0 |
| Maombi | TV Sets |
| Azimio | 1366×768 |
| Muundo | CELL , a-Si TFT-LC |
| Mwangaza | |
| CR | 1200:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | No |
| Kiolesura | LVDS |
| mtengenezaji | BOE |
| ukubwa wa skrini | 32.0 inch |
| nambari ya pixel | 1366(RGB)×768 (WXGA) 49PPI |
| eneo amilifu(mm) | 697.685 × 392.256 (H×V) |
| eneo la bezel(mm) | - |
| mwangaza | 0 cd/m² |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10) |
| mtazamo mzuri | Symmetry |
| unene wa kioo | 0.50+0.50 mm |
| kina cha rangi | 16.7M 72% NTSC |
| wingi | 877g (Typ.) |
| kiwango cha upya | 60Hz |
| orodha ya dereva | Built-in COF 2 source chips |
| aina ya ishara | LVDS (1 ch, 8-bit) , 30 pins Connector |
| usambazaji wa voltage | 12V (Typ.) |
| max. ukadiriaji | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| jina la mfano | HV320WHB-N5M |
| aina ya skrini | CELL , a-Si TFT-LCD |
| mpangilio | RGB Vertical Stripe |
| muhtasari(mm) | 715 × 411 × 1.32 (H×V×D) |
| matibabu | Antiglare (Haze 1%), Hard coating (3H) |
| uwiano wa utofautishaji | 1200 : 1 (Typ.) (TM) |
| majibu | 8 (Typ.)(G to G) ms |
| hali ya kazi | ADS, Normally Black, Transmissive |
| uhamishaji | 6.1% (Typ.)(with Polarizer) |
| backlight | No B/L |
| kutumika kwa | TV Sets |
| skrini ya kugusa | Without |
| HV320WHB-N00 | BOE | 31.5 | 1366×768 |
| HV320WHB-N06 | BOE | 31.5 | 1366×768 |
| HV320WHB-N80 | BOE | 31.5 | 1366×768 |
| HV320WX2-200 | BOE | 31.5 | 1366×768 |
| HV320WX2-201 | BOE | 31.5 | 1366×768 |
| HV320WX2-206 | BOE | 31.5 | 1366×768 |
| HV320WX2-500 | BOE | 31.5 | 1366×768 |
| HV320WXC-100 | BOE | 31.5 | 1366×768 |
| HV320WXC-201 | BOE | 31.5 | 1366×768 |
| V320B1-L06 | Innolux | 32.0 | 1366×768 |
