| Nambari ya Sehemu | HV550QUB-H13 |
| Chapa | BOE |
| Ukubwa | 55 |
| Maombi | TV Sets |
| Azimio | 38403×2160 |
| Muundo | a-Si TFT-LCD , CELL |
| Mwangaza | |
| CR | 1200:1 |
| Rangi | 1.07B |
| Mwangaza nyuma | No |
| Kiolesura | V-by-One |
| chapa ya paneli | BOE |
| saizi ya paneli | 55" |
| azimio | 3840(3)×2160, UHD, 80PPI |
| eneo la maonyesho | 1209.6(W)×680.4(H) mm |
| saizi ya muhtasari | 1225.2(W)×696.7(H) ×1.34(D) mm |
| mwangaza | 0 cd/m² |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10) |
| mwonekano bora zaidi | Symmetry |
| kioo kina | 0.50+0.50 mm |
| kuonyesha rangi | 1.07B 73% NTSC |
| masafa | 120Hz |
| dereva ic | COF Built-in 6 source chips |
| uzito wa paneli | 2.60Kgs (Typ.) |
| kiolesura cha ishara | V-by-One 8 lane , 60 pins Connector |
| voltage ya pembejeo | 12.0V (Typ.) |
| mazingira | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| mfano wa paneli | HV550QUB-H13 |
| aina ya paneli | a-Si TFT-LCD , CELL |
| muundo wa pixel | RGBW Vertical Stripe |
| ufunguzi wa bezel | - |
| uso | Antiglare (Haze 1%), Hard coating (3H) |
| uwiano wa utofautishaji | 1200:1 (Typ.) (TM) |
| hali ya kuonyesha | ADS, Normally Black, Transmissive |
| wakati wa majibu | 8 (Typ.)(G to G) |
| uhamishaji | 7.15% (Typ.)(with Polarizer) |
| aina ya taa | No B/L |
| skrini ya kugusa | Without |
| maombi | TV Sets |
