| Nambari ya Sehemu | HV550QUB-N8D |
| Chapa | BOE |
| Ukubwa | 55 |
| Maombi | TV Sets |
| Azimio | 3840×2160 |
| Muundo | CELL , a-Si TFT-LC |
| Mwangaza | |
| CR | 1200:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | No |
| Kiolesura | V-by-One |
| mtengenezaji | BOE |
| ukubwa wa skrini | 55 inch |
| nambari ya pixel | 3840(RGB)×2160 (UHD) 80PPI |
| eneo amilifu(mm) | 1209.6 × 680.4 (H×V) |
| eneo la bezel(mm) | - |
| mwangaza | 0 cd/m² |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10) |
| mtazamo mzuri | Symmetry |
| unene wa kioo | 0.50+0.50 mm |
| kina cha rangi | 16.7M 76% NTSC |
| wingi | 2.70Kgs (Typ.) |
| kiwango cha upya | 60Hz |
| orodha ya dereva | Built-in COF 12 source chips |
| aina ya ishara | V-by-One 8 lane , 51 pins Connector |
| usambazaji wa voltage | 12.0V (Typ.) |
| max. ukadiriaji | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| jina la mfano | HV550QUB-N8D |
| aina ya skrini | CELL , a-Si TFT-LCD |
| mpangilio | RGB Vertical Stripe |
| muhtasari(mm) | 1221.4 × 694.8 × 1.34 (H×V×D) |
| matibabu | Antiglare (Haze 1%), Hard coating (2H) |
| uwiano wa utofautishaji | 1200 : 1 (Typ.) (TM) |
| majibu | 8 (Typ.)(G to G) ms |
| hali ya kazi | ADS, Normally Black, Transmissive |
| uhamishaji | 5.3% (Typ.)(with Polarizer) |
| backlight | No B/L |
| kutumika kwa | TV Sets |
| skrini ya kugusa | Without |
| ASI545FB01-0 | Samsung | 55 | 1920×1080 |
| HV550QUB-B10 | BOE | 55 | 3840×2160 |
| LC550EUD-SCA2 | LG Display | 55 | 1920×1080 |
| LC550EUF-FGF1 | LG Display | 55 | 1920×1080 |
| LC550EUG-PFF1 | LG Display | 55 | 1920×1080 |
| LC550EUH-RDA2 | LG Display | 55 | 1920×1080 |
| LC550EUN-SFM2 | LG Display | 55 | 1920×1080 |
| LTA550HJ05 | Samsung | 55 | 1920×1080 |
| LTF550HF01 | Samsung | 55 | 1920×1080 |
| P546HW03 V0 | AUO | 55 | 1920×1080 |
