| Nambari ya Sehemu | JJ103IA-12A |
| Chapa | Innolux |
| Ukubwa | 10.3 |
| Maombi | Outdoor High Brightn |
| Azimio | 1920×720 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 1300:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 4 |
| Kiolesura | LVDS |
| chapa ya paneli | Innolux |
| saizi ya paneli | 10.3" |
| azimio | 1920(RGB)×720, 200PPI |
| eneo la maonyesho | 243.648(W)×91.368(H) mm |
| saizi ya muhtasari | 255.24(W)×106.68(H) mm |
| mwangaza | 800 cd/m² (Typ.) |
| angle ya kutazama | 80/80/80/80 (Min.)(CR≥10) |
| mwonekano bora zaidi | Symmetry |
| kuonyesha rangi | 16.7M 71% NTSC |
| masafa | 60Hz |
| uzito wa paneli | 380g (Max.) |
| kiolesura cha ishara | LVDS (2 ch, 8-bit) , 50 pins Connector |
| voltage ya pembejeo | 3.3V (Typ.) |
| mazingira | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| mfano wa paneli | JJ103IA-12A |
| aina ya paneli | a-Si TFT-LCD , LCM |
| muundo wa pixel | RGB Vertical Stripe |
| ufunguzi wa bezel | 246.65(W)×94.37(H) mm |
| uso | Antiglare |
| uwiano wa utofautishaji | 1300:1 (Typ.) (TM) |
| hali ya kuonyesha | IPS, Normally Black, Transmissive |
| wakati wa majibu | 27 (Typ.)(Tr+Td) |
| aina ya taa | 4 strings WLED , 10K hours , Without Driver |
| skrini ya kugusa | Without |
| maombi | Outdoor High Brightness Automotive Display |
