| Nambari ya Sehemu | KHS038AA1AG-G83 |
| Chapa | Kyocera |
| Ukubwa | 3.8 |
| Maombi | Industrial |
| Azimio | 240×320 |
| Muundo | LCM , CSTN-LCD |
| Mwangaza | |
| CR | 15:1 |
| Rangi | Color |
| Mwangaza nyuma | 1 |
| Kiolesura | Parallel |
| mtengenezaji | Kyocera |
| ukubwa wa skrini | 3.8 inch |
| nambari ya pixel | 240(RGB)×320 (QVGA) 105PPI |
| eneo amilifu(mm) | 57.58 × 76.78 (H×V) |
| mwangaza | 16 cd/m² (Typ.) |
| angle ya kutazama | 50/45/20/30 (Typ.)(CR≥2) |
| mtazamo mzuri | - |
| kina cha rangi | Color |
| wingi | - |
| kiwango cha upya | 75Hz |
| aina ya ishara | Parallel Data (1ch, 8-bit) FPC |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| jina la mfano | KHS038AA1AG-G83 |
| aina ya skrini | LCM , CSTN-LCD |
| mpangilio | RGB Vertical Stripe |
| muhtasari(mm) | - |
| uwiano wa utofautishaji | 15 : 1 (Typ.) (TM) |
| majibu | 250/150 (Typ.)(Tr/Td) ms |
| hali ya kazi | STN, Normally Black, Transflective |
| backlight | 1 pcs CCFL , No Driver |
| kutumika kwa | Industrial |
| skrini ya kugusa | - |
