| Nambari ya Sehemu | LA084X02-SL01 |
| Chapa | LG Display |
| Ukubwa | 8.4 |
| Maombi | Automotive Display |
| Azimio | 1024×768 |
| Muundo | LCM, a-Si TFT-LCD |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.2M |
| Mwangaza nyuma | 10S3P |
| Kiolesura | LVDS |
| mtengenezaji | LG Display |
| jina la mfano | LA084X02-SL01 |
| ukubwa wa skrini | 8.4 inch |
| aina ya skrini | LCM, a-Si TFT-LCD |
| nambari ya pixel | 1024(RGB)×768 (XGA) 152PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 170.496 × 127.872 (H×V) |
| muhtasari(mm) | 184.5 × 143 × 9.95 (H×V×D) |
| mwangaza | 1200 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000 : 1 (Typ.) (TM) |
| angle ya kutazama | 89/89/89/89 (Min.)(CR≥10) |
| majibu | 40 (Max.)(Tr+Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | IPS, Normally Black, Transmissive |
| kina cha rangi | 16.2M 70% NTSC |
| backlight | 10S3P WLED , No Driver |
| wingi | 255/260g (Typ./Max.) |
| kutumika kwa | Automotive Display |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | LVDS (1 ch, 8-bit) , FPC 40 pins |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -40 ~ 90 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 2.84G (27.8 m/s²) |
| AA084VB01 | Mitsubishi | 8.4 | 640×480 |
| AM-800600M3TNQW-00H | AMPIRE | 8.4 | 800×600 |
| G084SN03 V1 | AUO | 8.4 | 800×600 |
| LQ084S3LG03 | SHARP | 8.4 | 800×600 |
| LQ084V1DG22 | SHARP | 8.4 | 640×480 |
| LQ9D01C | SHARP | 8.4 | 640×480 |
| LQ9D023 | SHARP | 8.4 | 640×480 |
| LQ9D03B | SHARP | 8.4 | 640×480 |
| LTM08C355S | TOSHIBA | 8.4 | 800×600 |
| NL6448BC26-25 | NLT | 8.4 | 640×480 |
