| Nambari ya Sehemu | LA121WH1-SL02 |
| Chapa | LG Display |
| Ukubwa | 12.1 |
| Maombi | Automotive Display |
| Azimio | 1280×720 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 8S3P |
| Kiolesura | LVDS |
| mtengenezaji | LG Display |
| jina la mfano | LA121WH1-SL02 |
| ukubwa wa skrini | 12.1 inch |
| aina ya skrini | LCM , a-Si TFT-LCD |
| nambari ya pixel | 1280(RGB)×720 (WXGA) 121PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 266.88 × 150.12 (H×V) |
| muhtasari(mm) | 287.4 × 163.45 × 9.51 (H×V×D) |
| eneo la bezel(mm) | 269.65 × 152.55 (H×V) |
| matibabu | Antiglare |
| mwangaza | 500 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000 : 1 (Typ.) (TM) |
| angle ya kutazama | 80/80/80/80 (Min.)(CR≥10) |
| majibu | 17/13 (Max.)(Tr+Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | IPS, Normally Black, Transmissive |
| kina cha rangi | 16.7M 62% NTSC |
| backlight | 8S3P WLED , 10K hours , No Driver |
| wingi | 417±5g |
| kutumika kwa | Automotive Display |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | LVDS (1 ch, 8-bit) , 40 pins Connector |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
