| Nambari ya Sehemu | LA123WF1-SR02 |
| Chapa | LG Display |
| Ukubwa | 12.3 |
| Maombi | Automotive Display |
| Azimio | 1920×720 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | RSDS |
| chapa | LG Display |
| ukubwa wa diagonal | 12.3 inch |
| muundo wa pixel | 1920(RGB)×720 167PPI |
| eneo la kazi | 292.032(H)×109.512(V) mm |
| eneo la bezel | - |
| mwangaza | 600 cd/m² (Min.) |
| tazama mwelekeo | Symmetry |
| angle ya kutazama | 89/89/89/89 (Min.)(CR≥10) |
| rangi ya msaada | 16.7M 86% NTSC |
| uzito | 390/405g (Typ./Max.) |
| kiwango cha fremu | 60Hz |
| aina ya kiolesura | RSDS (2 Channel) , 110 pins FPC |
| usambazaji wa nguvu | 3.3/13.0V (Typ.)(VCC/VDD) |
| mazingira | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| mfano | LA123WF1-SR02 |
| aina | a-Si TFT-LCD , LCM |
| usanidi | RGB Vertical Stripe |
| muhtasari dim. | 310(H)×128(V) ×11.05(D) mm |
| matibabu | Antiglare, Antireflection |
| uwiano wa utofautishaji | 800:1 (Min.) (TM) |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| hali ya uendeshaji | IPS, Normally Black, Transmissive |
| chanzo cha mwanga | WLED [8S6P] , 10K hours , W/O Driver |
| iliyoundwa kwa ajili ya | Automotive Display |
| jopo la kugusa | Without |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
