| Nambari ya Sehemu | LM081HB1T01 |
| Chapa | SHARP |
| Ukubwa | 8.1 |
| Maombi | IA |
| Azimio | 640×240 |
| Muundo | LCM |
| Mwangaza | 150 |
| CR | 8:1 |
| Rangi | Monochrome |
| Mwangaza nyuma | CCFL |
| Kiolesura | Parallel Data |
| chapa ya paneli | SHARP |
| mfano wa paneli | LM081HB1T01 |
| aina ya paneli | FSTN-LCD , LCM |
| saizi ya paneli | 8.1 inch |
| azimio | 640×240 , HVGA |
| hali ya kuonyesha | STN, Black/White (Negative) |
| eneo la kazi | 191.99×71.99 mm |
| muhtasari | 249×99.4 mm |
| uso | |
| mwangaza | 150 cd/m² (Typ.) |
| uwiano wa utofautishaji | 8 : 1 (Typ.) |
| kuonyesha rangi | Monochrome |
| wakati wa majibu | 430/170 (Typ.)(Tr/Td) |
| angle ya kutazama | 30/30/20/35 (Typ.)(CR≥2)(L/R/U/D) |
| aina ya taa | 1 pcsCCFLWithout Driver |
| kiolesura cha ishara | Parallel Data (4-bit), 15 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | IA |
