LG Display LM170E03-TLJ5 hifadhidata, vipimo, hisa, programu www.looklcd-mk.com
LookLCD LookLCD


LM170E03-TLJ5

LM170E03-TLJ5
LM170E03-TLJ5
LM170E03-TLJ5
LM170E03-TLJ5 thumb LM170E03-TLJ5 thumb LM170E03-TLJ5 thumb
Chapa
LG Display
Ukubwa
17.0
Maombi
DMPC
Azimio
1280×1024
Muundo
LCM
Mwangaza
250
CR
1000:1
Rangi
16.7M
Mwangaza nyuma
CCFL
Kiolesura
LVDS
In Stock
80
Vipimo

Nambari ya Sehemu LM170E03-TLJ5
ChapaLG Display
Ukubwa17.0
MaombiDMPC
Azimio1280×1024
MuundoLCM
Mwangaza250
CR1000:1
Rangi16.7M
Mwangaza nyumaCCFL
KiolesuraLVDS
chapa ya paneliLG Display
mfano wa paneliLM170E03-TLJ5 1 Compatible model
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli17.0 inch
azimio1280(RGB)×1024 , SXGA
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi337.92×270.336 mm
muhtasari358.5×296.5×14 mm
usoAntiglare, Hard coating (3H)
mwangaza250 cd/m² (Typ.)
uwiano wa utofautishaji1000:1 (Typ.)
kuonyesha rangi16.7M (6-bit + Hi-FRC)
wakati wa majibu1.2/3.8 (Typ.)(Tr/Td)
angle ya kutazama85/85/75/85 (Typ.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taa2 pcsCCFLWithout Driver
kiolesura cha isharaLVDS (2 ch, 8-bit), 30 pins
voltage ya pembejeo5.0V (Typ.)
maombiDMPC
Mfano wa Familia
LM170E01-A4 LG Display 17.0 1280×1024
LM170E01-A6 LG Display 17.0 1280×1024
LM170E01-TLA1 LG Display 17.0 1280×1024
LM170E01-TLB3 LG Display 17.0 1280×1024
LM170E03-TLB1 LG Display 17.0 1280×1024
LM170E03-TLG1 LG Display 17.0 1280×1024
LM170E03-TLJ2 LG Display 17.0 1280×1024
LM170E03-TLJ5 LG Display 17.0 1280×1024
LM170E03-TLL1 LG Display 17.0 1280×1024
LM170E03-TLL2 LG Display 17.0 1280×1024
Bidhaa Moto
LM190E08-TLJ8 LG Display 19.0 1280×1024
LM238WF2-SSG2 LG Display 23.8 1920×1080
LM270WF1-TLA1 LG Display 27.0 1920×1080
LM270WQ1-SDBV LG Display 27.0 2560×1440
LQ181E1LW31 SHARP 18.1 1280×1024
LTM181E4-L01 Samsung 18.1 1280×1024
LTM185AT01 Samsung 18.5 1366×768
LTM340YP01 Samsung 34 3440×1440
M170E5-L09 Innolux 17.0 1280×1024
NL160120BC27-09 NLT 21.3 1600×1200
