| Nambari ya Sehemu | LM171WX3-TLA1 |
| Chapa | LG Display |
| Ukubwa | 17.1 |
| Maombi | DMPC |
| Azimio | 1440×900 |
| Muundo | LCM |
| Mwangaza | 250 |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | LG.Philips LCD |
| mfano wa paneli | LM171WX3-TLA1 4 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 17.1 inch |
| azimio | 1440(RGB)×900 , WXGA+ |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 367.2×229.5 mm |
| muhtasari | 389.2×254.5×12 mm |
| uso | Antiglare (Haze 12%), Hard coating (3H) |
| mwangaza | 250 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) |
| kuonyesha rangi | 16.7M (6-bit + Hi-FRC), CIE193160% |
| wakati wa majibu | 2/6 (Typ.)(Tr/Td) |
| angle ya kutazama | 80/80/75/85 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 2 pcsCCFLWithout Driver |
| kiolesura cha ishara | LVDS (2 ch, 8-bit), 30 pins |
| voltage ya pembejeo | 5.0V (Typ.) |
| maombi | DMPC |
