| Nambari ya Sehemu | LP101WH1-TLB2 |
| Chapa | LG Display |
| Ukubwa | 10.1 |
| Maombi | NBPC |
| Azimio | 1366×768 |
| Muundo | LCM |
| Mwangaza | 200 |
| CR | 300:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | LG Display |
| mfano wa paneli | LP101WH1-TLB2 1 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.1 inch |
| azimio | 1366(RGB)×768 , WXGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 222.73×125.22 mm |
| muhtasari | 235×143×5.2 mm |
| mtindo wa sura | Wedge (PCBA Bent, Depth ≥5.2mm) |
| uso | Antiglare |
| mwangaza | 200 cd/m² (Typ.) |
| uwiano wa utofautishaji | 300:1 (Min.) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | 16 (Typ.)(Tr+Td) |
| angle ya kutazama | 30/30/10/20 (Min.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 4 stringsWLEDEmbedded (LED Driver) |
| kiolesura cha ishara | LVDS (1 ch, 6-bit), 40 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | NBPC |
| LP101WH1-TLA1 | LG Display | 10.1 | 1366×768 |
| LP101WH1-TLB1 | LG Display | 10.1 | 1366×768 |
| LP101WH1-TLB5 | LG Display | 10.1 | 1366×768 |
| LP101WH2-TLA2 | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLA3 | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLA6 | LG Display | 10.1 | 1366×768 |
| LP101WS1-TLA1 | LG Display | 10.1 | 1024×576 |
| LP101WS1-TLB2 | LG Display | 10.1 | 1024×576 |
| LP101WSA-TLA1 | LG Display | 10.1 | 1024×600 |
| LP101WX1-SLB1 | LG Display | 10.1 | 1280×800 |
| LP133WX1-TLN3 | LG Display | 13.3 | 1280×800 |
| LP140WH1-TLC3 | LG Display | 14.0 | 1366×768 |
| LP154W01-TLAA | LG Display | 15.4 | 1280×800 |
| LP171WX2-TLB2 | LG Display | 17.1 | 1440×900 |
| LQ106K1LA02 | SHARP | 10.6 | 1280×768 |
| LTD133KX2S | TOSHIBA | 13.3 | 1280×800 |
| LTN140AT06-A01 | Samsung | 14.0 | 1366×768 |
| N134B6-L04 | Innolux | 13.4 | 1366×768 |
| N140BGE-LB2 | Innolux | 14.0 | 1366×768 |
| N141X6-L01 | Innolux | 14.1 | 1024×768 |
