LP125WH2-TLB1

LP125WH2-TLB1
LP125WH2-TLB1
LP125WH2-TLB1
LP125WH2-TLB1 thumb LP125WH2-TLB1 thumb LP125WH2-TLB1 thumb
Chapa
LG Display
Ukubwa
12.5
Maombi
NBPC
Azimio
1366×768
Muundo
LCM
Mwangaza
200
CR
300:1
Rangi
262K
Mwangaza nyuma
WLED
Kiolesura
LVDS
In Stock
2567
Vipimo

Nambari ya Sehemu LP125WH2-TLB1
ChapaLG Display
Ukubwa12.5
MaombiNBPC
Azimio1366×768
MuundoLCM
Mwangaza200
CR300:1
Rangi262K
Mwangaza nyumaWLED
KiolesuraLVDS
chapa ya paneliLG Display
mfano wa paneliLP125WH2-TLB1
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli12.5 inch
azimio1366(RGB)×768 , WXGA
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi276.615×155.52 mm
muhtasari300.4×179.5×3.7 mm
mtindo wa suraFlat (PCBA Flat, Depth 3.4~4.0mm)
usoAntiglare
mwangaza200 cd/m² (Typ.)
uwiano wa utofautishaji300:1 (Typ.)
kuonyesha rangi262K (6-bit), CIE193145%
wakati wa majibu16 (Typ.)(Tr+Td)
angle ya kutazama45/45/15/35 (Typ.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taaWLEDEmbedded (LED Driver)
kiolesura cha isharaLVDS (1 ch, 6-bit), 40 pins
voltage ya pembejeo3.3V (Typ.)
maombiNBPC
