| Nambari ya Sehemu | LQ042Q1DW40P |
| Chapa | Sharp |
| Ukubwa | 4.2 |
| Maombi | Portable Navigation |
| Azimio | 320×320 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | Parallel |
| chapa | Sharp |
| mfano | LQ042Q1DW40P |
| ukubwa wa diagonal | 4.2 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 320(RGB)×320 [QVGA] 108PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 84.96(H)×63.72(V) mm |
| muhtasari dim. | 96.8(H)×71.5(V) mm |
| eneo la bezel | - |
| matibabu | Antiglare, Hard coating (3H) |
| mwangaza | 180 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) (TM) |
| tazama mwelekeo | - |
| wakati wa majibu | 35/35 (Typ.)(Tr/Td) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| hali ya uendeshaji | TN, Normally White, Transmissive |
| rangi ya msaada | 16.7M |
| chanzo cha mwanga | WLED [6S1P] , W/O Driver |
| uzito | 39.0g (Typ.) |
| iliyoundwa kwa ajili ya | Portable Navigation |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| aina ya kiolesura | Parallel RGB (1 ch, 8-bit) , 53 pins FPC |
| usambazaji wa nguvu | 1.8/5.0/-5.0/14.5/-14.5V (Typ.)(VSHD/VSHA/GVSS/VGH/VGL) |
| mazingira | Operating Temperature: 0 ~ 40 °C ; Storage Temperature: -25 ~ 60 °C |
| HVA42WV1-M00 | HYDIS | 4.2 | 480×800 |
| LQ042B5DG02 | SHARP | 4.2 | 400×96 |
| LQ042T5DZ01 | SHARP | 4.2 | 480×272 |
| LQ042T5DZ01A | SHARP | 4.2 | 480×272 |
| LQ042T5DZ11 | SHARP | 4.2 | 480×272 |
| LT042MDV5000 | JDI | 4.2 | 768×1280 |
