| Nambari ya Sehemu | LQ197V1LC17 |
| Chapa | SHARP |
| Ukubwa | 19.7 |
| Maombi | LCTV |
| Azimio | 640×480 |
| Muundo | LCM |
| Mwangaza | 260 |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | SHARP |
| mfano wa paneli | LQ197V1LC17 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 19.7 inch |
| azimio | 640(RGB)×480 , VGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 401.28×298.8 mm |
| muhtasari | 448.1×340.1 mm |
| uso | Hard coating (2H) |
| mwangaza | 260 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| angle ya kutazama | 60/60/45/55 (Typ.)(CR≥10)(L/R/U/D) |
| aina ya taa | 4 pcsCCFLWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 6-bit), 20 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | LCTV |
