| Nambari ya Sehemu | LQ800D3HA01 |
| Chapa | Sharp |
| Ukubwa | 80 |
| Maombi | TV Sets |
| Azimio | 1920×1080 |
| Muundo | a-Si TFT-LCD, CELL |
| Mwangaza | |
| CR | 5000:1 |
| Rangi | 1.07B |
| Mwangaza nyuma | No |
| Kiolesura | LVDS |
| chapa ya paneli | Sharp |
| mfano wa paneli | LQ800D3HA01 |
| saizi ya paneli | 80" |
| aina ya paneli | a-Si TFT-LCD, CELL |
| azimio | 1920(RGB)×1080, FHD, 27PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 1771.2(W)×996.3(H) mm |
| ufunguzi wa bezel | - |
| saizi ya muhtasari | 1802.6(W)×1026.9(H) ×1.7(D) mm |
| uso | Antiglare (Haze 3%), Hard coating (2H) |
| mwangaza | 0 cd/m² |
| uwiano wa utofautishaji | 5000:1 (Typ.) (TM) |
| angle ya kutazama | 88/88/88/88 (Typ.)(CR≥10) |
| hali ya kuonyesha | ASV, Normally Black, Transmissive |
| mwonekano bora zaidi | Symmetry |
| wakati wa majibu | 4 (Typ.)(G to G) |
| kioo kina | - |
| uhamishaji | 6.51% (Typ.)(with Polarizer) |
| kuonyesha rangi | 1.07B 73% NTSC |
| aina ya taa | No B/L |
| masafa | 120Hz |
| skrini ya kugusa | Without |
| dereva ic | COF Built-in 16 source + 10 gate chips |
| uzito wa paneli | 7.80g (Typ.) |
| maombi | TV Sets |
| kiolesura cha ishara | LVDS (4 ch, 10-bit) , 92 pins Connector |
| voltage ya pembejeo | 12.0V (Typ.) |
| mazingira | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C |
