| Nambari ya Sehemu | LQ9D011 |
| Chapa | SHARP |
| Ukubwa | 8.4 |
| Maombi | IA |
| Azimio | 640×480 |
| Muundo | LCM |
| Mwangaza | 70 |
| CR | 60:1 |
| Rangi | 512 |
| Mwangaza nyuma | CCFL |
| Kiolesura | TTL |
| chapa ya paneli | SHARP |
| mfano wa paneli | LQ9D011 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 8.4 inch |
| azimio | 640(RGB)×480 , VGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 170.88×129.6 mm |
| muhtasari | 243.5×180 mm |
| uso | Antiglare, Hard coating (2H) |
| mwangaza | 70 cd/m² (Typ.) |
| uwiano wa utofautishaji | 60:1 (Typ.) |
| kuonyesha rangi | 512 (3-bit) |
| wakati wa majibu | 30/50 (Typ.)(Tr/Td) |
| angle ya kutazama | 45/45/10/30 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 2 pcsCCFLWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 3-bit), 21 pins |
| voltage ya pembejeo | 5.0V (Typ.)(VCC) |
| maombi | IA |
