| Nambari ya Sehemu | LS030Q7DH01 |
| Chapa | SHARP |
| Ukubwa | 3.0 |
| Maombi | MPH |
| Azimio | 240×320 |
| Muundo | LCM |
| Mwangaza | 100 |
| CR | 70:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | SHARP |
| mfano wa paneli | LS030Q7DH01 |
| aina ya paneli | CG-Silicon , LCM |
| saizi ya paneli | 3.0 inch |
| azimio | 240(RGB)×320 , QVGA |
| hali ya kuonyesha | TN, Normally White, Transflective |
| eneo la kazi | 45.72×60.96 mm |
| muhtasari | 54.5×75 mm |
| uso | Hard coating (3H) |
| mwangaza | 100 cd/m² (Typ.) |
| uwiano wa utofautishaji | 70:1 (Typ.)(Transmissive)2.5:1 (Typ.)(Reflective) |
| kuonyesha rangi | 262K (6-bit), CIE193165% |
| wakati wa majibu | 30/50 (Typ.)(Tr/Td) |
| angle ya kutazama | 40/40/40/40 (Typ.)(CR≥2)(L/R/U/D) |
| aina ya taa | 5S1PWLEDWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 6-bit), 51 pins |
| voltage ya pembejeo | 3.3/5.0/8.0/-4.0/-8.0V (Typ.)(VSHD/VSHA/VDD/VSSD/GVSS) |
| maombi | MPH |
| ACX465AKM-7 | JDI | 5.9 | 1080×1920 |
| CLAF055WB41 TXX | CPT | 5.5 | 720×1280 |
| DLC0240LZG-4 | Other | 2.4 | 240×320 |
| DLC0350SZG | Other | 3.5 | 480×640 |
| H497DAN01.0 | AUO | 5.0 | 1080×1920 |
| LH240Q29-SH04 | LG Display | 2.4 | 240×320 |
| OEL9M0039-Y-E | Other | 1.5 | 128×128 |
| TM032PDZ16B | Tianma | 3.2 | 320×480 |
| TM032PDZ17 | Tianma | 3.2 | 320×480 |
| TX10D121VM0AAA | JDI | 4.0 | 480×800 |
