| Nambari ya Sehemu | LS055R3SX01 |
| Chapa | Sharp |
| Ukubwa | 5.5 |
| Maombi | Mobile Phone |
| Azimio | 1536×2560 |
| Muundo | CG-Silicon , LCM |
| Mwangaza | |
| CR | 1280:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | MIPI |
| chapa | Sharp |
| ukubwa wa diagonal | 5.5 inch |
| muundo wa pixel | 1536(RGB)×2560 546PPI |
| eneo la kazi | 71.424(H)×119.04(V) mm |
| mwangaza | 460 cd/m² (Typ.) |
| tazama mwelekeo | Symmetry |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| rangi ya msaada | 16.7M 70% NTSC |
| uzito | 21.1g |
| kiwango cha fremu | 60Hz |
| aina ya kiolesura | MIPI (4 data lanes) , 32 pins Connector |
| usambazaji wa nguvu | 1.8/5.5/-5.5V (Typ.)(IOVDD/VSP/VSN) |
| mazingira | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| mfano | LS055R3SX01 |
| aina | CG-Silicon , LCM |
| usanidi | RGB Vertical Stripe |
| muhtasari dim. | 73.824(H)×126.44(V) ×1.4(D) mm |
| uwiano wa utofautishaji | 1280:1 (Typ.) (TM) |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| hali ya uendeshaji | New Mode2, Normally Black, Transmissive |
| chanzo cha mwanga | WLED [8S2P] , W/O Driver |
| iliyoundwa kwa ajili ya | Mobile Phone |
| jopo la kugusa | Without |
