| Nambari ya Sehemu | LSC480HN08-8 |
| Chapa | SAMSUNG |
| Ukubwa | 48 |
| Maombi | TV Sets |
| Azimio | 1920×1080 |
| Muundo | CELL, a-Si TFT-LCD |
| Mwangaza | |
| CR | 4000:1 |
| Rangi | 1.07B |
| Mwangaza nyuma | No |
| Kiolesura | LVDS |
| mtengenezaji | SAMSUNG |
| jina la mfano | LSC480HN08-8 |
| ukubwa wa skrini | 48 inch |
| aina ya skrini | CELL, a-Si TFT-LCD |
| nambari ya pixel | 1920×1080(RGB) (FHD) 46PPI |
| mpangilio | RGB Horizontal Stripe |
| eneo amilifu(mm) | 1054.08 × 592.92 (H×V) |
| muhtasari(mm) | 1068.08 × 608.92 × 1.3 (H×V×D) |
| eneo la bezel(mm) | - |
| matibabu | Antiglare, Hard coating (2H) |
| mwangaza | 0 cd/m² |
| uwiano wa utofautishaji | 4000 : 1 (Typ.) (TM) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10) |
| majibu | 8 (Typ.)(G to G) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | SVA, Normally Black, Transmissive |
| unene wa kioo | 0.40+0.50 mm |
| uhamishaji | 6.6% (Typ.)(with Polarizer) |
| kina cha rangi | 1.07B 68% NTSC |
| backlight | No B/L |
| wingi | 2.80Kgs (Typ.) |
| kutumika kwa | TV Sets |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| orodha ya dereva | Built-in COF 2 source chips |
| aina ya ishara | LVDS (2 ch, 10-bit) , Connector 51 pins |
| usambazaji wa voltage | 12.0V (Typ.) |
| max. ukadiriaji | Storage Temp.: -20 ~ 65 °C Operating Temp.: 0 ~ 50 °C |
