| Nambari ya Sehemu | LSC480HN10 |
| Chapa | SAMSUNG |
| Ukubwa | 48 |
| Maombi | TV Sets |
| Azimio | 1920×1080 |
| Muundo | a-Si TFT-LCD, CELL |
| Mwangaza | |
| CR | 4000:1 |
| Rangi | 1.07B |
| Mwangaza nyuma | No |
| Kiolesura | LVDS |
| chapa | SAMSUNG |
| mfano | LSC480HN10 |
| ukubwa wa diagonal | 48 inch |
| aina | a-Si TFT-LCD, CELL |
| muundo wa pixel | 1920×1080(RGB) [FHD] 46PPI |
| usanidi | RGB Horizontal Stripe |
| eneo la kazi | 1054.08(H)×592.92(V) mm |
| muhtasari dim. | 1068.08(H)×608.92(V) ×1.4(D) mm |
| eneo la bezel | - |
| matibabu | Antiglare, Hard coating (2H) |
| mwangaza | 0 cd/m² |
| uwiano wa utofautishaji | 4000:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 8 (Typ.)(G to G) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10) |
| hali ya uendeshaji | SVA, Normally Black, Transmissive |
| unene wa sahani | 0.50+0.50 mm |
| uhamishaji | 6.6% (Typ.)(with Polarizer) |
| rangi ya msaada | 1.07B 68% NTSC |
| chanzo cha mwanga | No B/L |
| uzito | 1.90Kgs (Typ.) |
| iliyoundwa kwa ajili ya | TV Sets |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| maelezo ya d-ic | COF Built-in 2 source chips |
| aina ya kiolesura | LVDS (2 ch, 10-bit) , 51 pins Connector |
| usambazaji wa nguvu | 12.0V (Typ.) |
| mazingira | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 65 °C |
| HV480FH2-600 | BOE | 48 | 1920×1080 |
| LSC480FJ01 | Samsung | 48 | 3840×2160 |
| ST4761B01-5 | CSOT | 48 | 1920×1080 |
| ST4761B02-1 | CSOT | 48 | 1920×1080 |
