| Nambari ya Sehemu | LTM12C505D |
| Chapa | TOSHIBA |
| Ukubwa | 12.1 |
| Maombi | NBPC |
| Azimio | 1024×768 |
| Muundo | LCM |
| Mwangaza | 165 |
| CR | 350:1 |
| Rangi | 262K |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | Toshiba Matsushita |
| mfano wa paneli | LTM12C505D |
| aina ya paneli | LTPS TFT-LCD , LCM |
| saizi ya paneli | 12.1 inch |
| azimio | 1024(RGB)×768 , XGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 245.76×184.32 mm |
| muhtasari | 261×199×5.3 mm |
| uso | |
| mwangaza | 165 cd/m² (Typ.) |
| uwiano wa utofautishaji | 350:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | 50/50 (Max.)(Tr/Td) |
| angle ya kutazama | |
| masafa | 60Hz |
| aina ya taa | 1 pcsCCFLEmbedded (Inverter) |
| kiolesura cha ishara | LVDS (1 ch, 6-bit), 20 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | NBPC |
