| Nambari ya Sehemu | LTN106W1-L01 |
| Chapa | Samsung |
| Ukubwa | 10.6 |
| Maombi | NBPC |
| Azimio | 1280×768 |
| Muundo | LCM |
| Mwangaza | 185 |
| CR | 250:1 |
| Rangi | 262K |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | SAMSUNG |
| mfano wa paneli | LTN106W1-L01 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.6 inch |
| azimio | 1280(RGB)×768 , WXGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 230.4×138.24 mm |
| muhtasari | 243.4×152 mm |
| uso | Antiglare (Haze 25%), Hard coating (3H) |
| mwangaza | 185 cd/m² (Typ.) |
| uwiano wa utofautishaji | 250:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | 10/30 (Typ.)(Tr/Td) |
| angle ya kutazama | 45/45/15/30 (Min.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 1 pcsCCFLWithout Driver |
| kiolesura cha ishara | LVDS (2 ch, 6-bit), 30 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | NBPC |
