| Nambari ya Sehemu | M102AWF2 R1 |
| Chapa | IVO |
| Ukubwa | 10.3 |
| Maombi | Automotive Display |
| Azimio | 1920×720 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa | IVO |
| mfano | M102AWF2 R1 |
| ukubwa wa diagonal | 10.3 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1920(RGB)×720 200PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 243.65(H)×91.37(V) mm |
| muhtasari dim. | 262.04(H)×110.3(V) ×12.2(D) mm |
| eneo la bezel | 245.65(H)×93.66(V) mm |
| matibabu | Hard coating (3H) |
| mwangaza | 800 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 20 (Typ.)(Tr+Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| hali ya uendeshaji | IPS, Normally Black, Transmissive |
| rangi ya msaada | 16.7M 72% NTSC |
| chanzo cha mwanga | WLED [8S3P] , 10K hours , W/O Driver |
| uzito | 380g (Max.) |
| iliyoundwa kwa ajili ya | Automotive Display |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| aina ya kiolesura | LVDS (2 ch, 8-bit) , 50 pins Connector |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 3.0G (29.4 m/s²) |
