| Nambari ya Sehemu | M236H1-L01 |
| Chapa | Innolux |
| Ukubwa | 23.6 |
| Maombi | DMPC |
| Azimio | 1920×1080 |
| Muundo | LCM |
| Mwangaza | 300 |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | CMO |
| mfano wa paneli | M236H1-L01 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 23.6 inch |
| azimio | 1920(RGB)×1080 , FHD |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 521.28×293.22 mm |
| muhtasari | 544.8×320.5×19.2 mm |
| uso | Antiglare (Haze 25%), Hard coating (3H) |
| mwangaza | 300 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) |
| kuonyesha rangi | 16.7M (6-bit + Hi-FRC), CIE193172% |
| wakati wa majibu | 1.5/3.5 (Typ.)(Tr/Td) |
| angle ya kutazama | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 4 pcsCCFLWithout Driver |
| kiolesura cha ishara | LVDS (2 ch, 8-bit), 30 pins |
| voltage ya pembejeo | 5.0V (Typ.) |
| maombi | DMPC |
| M236H1-L01 | Innolux | 23.6 | 1920×1080 |
| M236H1-L07 | Innolux | 23.6 | 1920×1080 |
| M236H3-L05 | Innolux | 23.6 | 1920×1080 |
| M236H3-LA2 | Innolux | 23.6 | 1920×1080 |
| M236H3-LA3 | Innolux | 23.6 | 1920×1080 |
| M236HGE-L20 | Innolux | 23.6 | 1920×1080 |
| M236HGJ-L11 | Innolux | 23.6 | 1920×1080 |
| M236HGK-L30 | Innolux | 23.6 | 1920×1080 |
| M236HJJ-L30 | Innolux | 23.6 | 1920×1080 |
| M236HJK-L3B | Innolux | 23.6 | 1920×1080 |
| HT190WG3-500 | BOE | 19.0 | 1440×900 |
| LM171WX3-TLB2 | LG Display | 17.1 | 1440×900 |
| LM270WR2-SPA1 | LG Display | 27.0 | 3840×2160 |
| LTM200KT07 | Samsung | 20.0 | 1600×900 |
| M156B3-L01 | Innolux | 15.6 | 1366×768 |
| M185XTN01.2 | AUO | 18.5 | 1366×768 |
| M215HGE-P02 | Innolux | 21.5 | 1920×1080 |
| M270HHF-L10 | Innolux | 27.0 | 1920×1080 |
| NL128102BC29-01C | NLT | 19.0 | 1280×1024 |
| TX43D14VC0CAB | KOE | 17.0 | 1280×1024 |
