| Nambari ya Sehemu | M238DAN01.1Q0 |
| Chapa | AUO |
| Ukubwa | 23.8 |
| Maombi | Desktop Monitor |
| Azimio | 2560×1440 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 20S4P |
| Kiolesura | LVDS |
| chapa ya paneli | AUO |
| mfano wa paneli | M238DAN01.1Q0 |
| saizi ya paneli | 23.8" |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 2560(RGB)×1440, Quad-HD, 123PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 526.85(W)×296.35(H) mm |
| ufunguzi wa bezel | - |
| saizi ya muhtasari | 534.74(W)×313.26(H) ×12.3(D) mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 300 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) (TM) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10) |
| hali ya kuonyesha | AHVA, Normally Black, Transmissive |
| mwonekano bora zaidi | Symmetry |
| wakati wa majibu | 14 (Typ.)(G to G) |
| kuonyesha rangi | 16.7M 100% sRGB |
| aina ya taa | 20S4P WLED , 30K hours , Without Driver |
| masafa | 60Hz |
| skrini ya kugusa | Without |
| uzito wa paneli | 2.20Kgs (Typ.) |
| maombi | Desktop Monitor |
| kiolesura cha ishara | LVDS (4 ch, 8-bit) , 92 pins Connector |
| voltage ya pembejeo | 5.0V (Typ.) |
| mazingira | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
