Nambari ya Sehemu | MC156CS08-1 |
Chapa | No Brand |
Ukubwa | 15.6 |
Maombi | Laptop |
Azimio | 1920×1080 |
Muundo | a-Si TFT-LCD, LCM |
Mwangaza | |
CR | 800:1 |
Rangi | 16.7M |
Mwangaza nyuma | WLED |
Kiolesura | eDP |
chapa | No Brand |
mfano | MC156CS08-1 |
ukubwa wa diagonal | 15.6 inch |
aina | a-Si TFT-LCD, LCM |
muundo wa pixel | 1920(RGB)×1080 [FHD] 141PPI |
usanidi | RGB Vertical Stripe |
eneo la kazi | 344.16(H)×193.59(V) mm |
muhtasari dim. | 359.5(H)×221.77(V) mm |
eneo la bezel | - |
matibabu | Antiglare, Hard coating (3H) |
mwangaza | 300 cd/m² (Typ.) |
uwiano wa utofautishaji | 800:1 (Typ.) (TM) |
tazama mwelekeo | Symmetry |
wakati wa majibu | 20 (Typ.)(G to G) |
angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
hali ya uendeshaji | HIS, Normally Black, Transmissive |
rangi ya msaada | 16.7M 45% NTSC |
chanzo cha mwanga | WLED [6 strings] , With LED Driver |
mtindo wa fomu | Slim (PCBA Flat, T≤3.2mm) |
iliyoundwa kwa ajili ya | Laptop |
kiwango cha fremu | 60Hz |
jopo la kugusa | Without |
aina ya kiolesura | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
usambazaji wa nguvu | 3.3V (Typ.) |
mazingira | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
