MT220WW01 V.6

MT220WW01 V.6
MT220WW01 V.6
MT220WW01 V.6 thumb MT220WW01 V.6 thumb
Chapa
Innolux
Ukubwa
22.0
Maombi
DMPC
Azimio
1680×1050
Muundo
LCM
Mwangaza
250
CR
1000:1
Rangi
16.7M
Mwangaza nyuma
CCFL
Kiolesura
LVDS
In Stock
3862
Vipimo

Nambari ya Sehemu MT220WW01 V.6
ChapaInnolux
Ukubwa22.0
MaombiDMPC
Azimio1680×1050
MuundoLCM
Mwangaza250
CR1000:1
Rangi16.7M
Mwangaza nyumaCCFL
KiolesuraLVDS
chapa ya paneliINNOLUX
mfano wa paneliMT220WW01 V.6
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli22.0 inch
azimio1680(RGB)×1050 , WSXGA+
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi473.76×296.1 mm
muhtasari493.7×320.1×16.7 mm
usoAntiglare (Haze 25%), Hard coating (3H)
mwangaza250 cd/m² (Typ.)
uwiano wa utofautishaji1000:1 (Typ.)
kuonyesha rangi16.7M (6-bit + Hi-FRC)
wakati wa majibu1.5/3.5 (Typ.)(Tr/Td)
angle ya kutazama85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taa2 pcsCCFLWithout Driver
kiolesura cha isharaLVDS (1 ch, 8-bit), 30 pins
voltage ya pembejeo5.0V (Typ.)
maombiDMPC
