Innolux N156BGE-L51 hifadhidata, vipimo, hisa, programu www.looklcd-mk.com

N156BGE-L51


Chapa
Innolux
Ukubwa
15.6
Maombi
NBPC
Azimio
1366×768
Muundo
LCM
Mwangaza
220
CR
500:1
Rangi
262K
Mwangaza nyuma
WLED
Kiolesura
LVDS
In Stock
13825
Vipimo

Nambari ya Sehemu N156BGE-L51
ChapaInnolux
Ukubwa15.6
MaombiNBPC
Azimio1366×768
MuundoLCM
Mwangaza220
CR500:1
Rangi262K
Mwangaza nyumaWLED
KiolesuraLVDS
chapa ya paneliCHIMEI INNOLUX
mfano wa paneliN156BGE-L51
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli15.6 inch
azimio1366(RGB)×768 , WXGA
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi344.232×193.536 mm
muhtasari359.3×222.45×4 mm
mtindo wa suraFlat (PCBA Flat, Depth 3.4~4.0mm)
usoAntiglare, Hard coating (3H)
mwangaza220 cd/m² (Typ.)
uwiano wa utofautishaji500:1 (Typ.)
kuonyesha rangi262K (6-bit)
wakati wa majibu3/5 (Typ.)(Tr/Td)
angle ya kutazama45/45/20/45 (Typ.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taaWLEDEmbedded (LED Driver)
kiolesura cha isharaLVDS (1 ch, 6-bit), 40 pins
voltage ya pembejeo3.3V (Typ.)
maombiNBPC
Mfano wa Familia
N156B3-L02 Innolux 15.6 1366×768
N156B3-L0B Innolux 15.6 1366×768
N156B6-L01 Innolux 15.6 1366×768
N156B6-L0A Innolux 15.6 1366×768
N156BGE-E21 Innolux 15.6 1366×768
N156BGE-EA1 Innolux 15.6 1366×768
N156BGE-L31 Innolux 15.6 1366×768
N156BGE-L41 Innolux 15.6 1366×768
N156BGE-L52 Innolux 15.6 1366×768
N156BGE-L62 Innolux 15.6 1366×768
