| Nambari ya Sehemu | N161HCA-EA3 |
| Chapa | Innolux |
| Ukubwa | 16.1 |
| Maombi | Laptop |
| Azimio | 1920×1080 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | eDP |
| mtengenezaji | Innolux |
| jina la mfano | N161HCA-EA3 (CMN1604) |
| ukubwa wa skrini | 16.1 inch |
| aina ya skrini | LCM , a-Si TFT-LCD |
| nambari ya pixel | 1920(RGB)×1080 (FHD) 137PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 355.39 × 199.91 (H×V) |
| muhtasari(mm) | 361.9 × 222.16 × 3.2 (H×V×D) |
| eneo la bezel(mm) | - |
| matibabu | Antiglare, Hard coating (3H) |
| mwangaza | 300 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000 : 1 (Typ.) (TM) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10) |
| majibu | 11/9 (Typ.)(Tr/Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | AAS, Normally Black, Transmissive |
| kina cha rangi | 16.7M 100% sRGB |
| backlight | WLED , 15K hours , With LED Driver |
| umbo la muhtasari | Slim (PCBA Flat, T≤3.2mm) |
| kutumika kwa | Laptop |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
