| Nambari ya Sehemu | ND078-101A1 |
| Chapa | SEBO |
| Ukubwa | 7.8 |
| Maombi | CNS |
| Azimio | 1280×400 |
| Muundo | LCM |
| Mwangaza | 700 |
| CR | 900:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | SEBO |
| mfano wa paneli | ND078-101A1 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.8 inch |
| azimio | 1280(RGB)×400 |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 190.08×59.4 mm |
| muhtasari | 205.78×67.8×7.25 mm |
| uso | |
| mwangaza | 700 cd/m² (Typ.) |
| uwiano wa utofautishaji | 900:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193160% |
| wakati wa majibu | 35 (Typ.)(Tr+Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 3S6PWLEDWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 8-bit), 40 pins |
| voltage ya pembejeo | 1.5/3.3/10/19/-8V (Typ.)(VCC/VDD/AVDD/VGH/VGL) |
| maombi | CNS |
| 70WVW1T | SII | 7.0 | 800×480 |
| CLAA069LA1AAW | CPT | 7.0 | 800×480 |
| DLC1040ABG-T-2 | Other | 10.4 | 800×600 |
| G070Y1-T01 | Innolux | 7.0 | 800×480 |
| L5F30614T23 | SANYO | 8.0 | 800×480 |
| LAJ080W001A | TPO | 8.0 | 800×480 |
| LQ042B5DG02 | SHARP | 4.2 | 400×96 |
| LQ050T5DG02 | SHARP | 5.0 | 400×240 |
| PA079DS1T3 | E Ink | 7.9 | 480×234 |
| YXDK050TN02-40NM03 | SEBO | 5.0 | 800×480 |
