| Nambari ya Sehemu | NL6448AC33-A0D |
| Chapa | NLT |
| Ukubwa | 10.4 |
| Maombi | Industrial |
| Azimio | 640×480 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 900:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | CMOS |
| chapa ya paneli | NLT |
| saizi ya paneli | 10.4" |
| azimio | 640(RGB)×480, VGA, 76PPI |
| eneo la maonyesho | 211.2(W)×158.4(H) mm |
| saizi ya muhtasari | 246.5(W)×179.4(H) ×10(D) mm |
| mwangaza | 500 cd/m² (Typ.) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| mwonekano bora zaidi | - |
| kuonyesha rangi | 262K 40% NTSC |
| masafa | 60Hz |
| uzito wa paneli | 390/435g (Typ./Max.) |
| kiolesura cha ishara | CMOS (1 ch, 6-bit) , 31 pins Connector |
| voltage ya pembejeo | 3.3/5.0V (Typ.) |
| mazingira | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| mfano wa paneli | NL6448AC33-A0D |
| aina ya paneli | a-Si TFT-LCD , LCM |
| muundo wa pixel | RGB Vertical Stripe |
| ufunguzi wa bezel | - |
| uso | Antiglare, Hard coating (3H) |
| uwiano wa utofautishaji | 900:1 (Typ.) (TM) |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| wakati wa majibu | 3/15 (Typ.)(Tr/Td) |
| aina ya taa | WLED , 100K hours , With LED Driver |
| skrini ya kugusa | Without |
| maombi | Industrial |
| NL6448AC20-06 | NLT | 6.5 | 640×480 |
| NL6448AC30-09 | NLT | 9.4 | 640×480 |
| NL6448AC30-10 | NLT | 9.4 | 640×480 |
| NL6448AC30-12 | NLT | 9.4 | 640×480 |
| NL6448AC33-05 | NLT | 10.4 | 640×480 |
| NL6448AC33-15 | NLT | 10.4 | 640×480 |
| NL6448AC33-18 | NLT | 10.4 | 640×480 |
| NL6448AC33-18A | NLT | 10.4 | 640×480 |
| NL6448AC33-24 | NLT | 10.4 | 640×480 |
| NL6448AC33-27 | NLT | 10.4 | 640×480 |
