| Nambari ya Sehemu | P101GWWC R5 |
| Chapa | IVO |
| Ukubwa | 10.1 |
| Maombi | Pad & Tablet |
| Azimio | 800×1280 |
| Muundo | a-Si TFT-LCD, CELL |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | No |
| Kiolesura | MIPI |
| chapa | IVO |
| mfano | P101GWWC R5 |
| ukubwa wa diagonal | 10.1 inch |
| aina | a-Si TFT-LCD, CELL |
| muundo wa pixel | 800(RGB)×1280 [WXGA] 150PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 135.36(H)×216.576(V) mm |
| muhtasari dim. | 139.36(H)×225.8(V) ×1.06(D) mm |
| eneo la bezel | - |
| matibabu | Antiglare |
| mwangaza | 0 cd/m² |
| uwiano wa utofautishaji | 1000:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| hali ya uendeshaji | IPS, Normally Black, Transmissive |
| unene wa sahani | 0.40+0.40 mm |
| uhamishaji | 6.2% (Typ.) |
| rangi ya msaada | 16.7M 60% NTSC |
| chanzo cha mwanga | No B/L |
| uzito | 85.0g (Max.) |
| iliyoundwa kwa ajili ya | Pad & Tablet |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| maelezo ya d-ic | COG Built-in 1 source chips |
| aina ya kiolesura | MIPI (4 data lanes) , 39 pins Connector |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| AM-1280800N2TZQW-00H | AMPIRE | 10.1 | 1280×800 |
| B101EAN01.2 | AUO | 10.1 | 1280×800 |
| B101EW05 V1 | AUO | 10.1 | 1280×800 |
| CLAA101WJ03 XG | CPT | 10.1 | 1366×768 |
| G101AGE-L01 | Innolux | 10.1 | 800×600 |
| HSD101PWW1-A00-C40 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-F01 | HannStar | 10.1 | 1280×800 |
| M101GWN9 R0 | IVO | 10.1 | 1024×600 |
| M101MWW4 R0 | IVO | 10.1 | 1024×600 |
| Q101IRE-LA1 | Innolux | 10.1 | 1280×800 |
