QD15XL13 Rev.01

QD15XL13 Rev.01
QD15XL13 Rev.01
QD15XL13 Rev.01 thumb QD15XL13 Rev.01 thumb
Chapa
QDI
Ukubwa
15.0
Maombi
DMPC
Azimio
1024×768
Muundo
LCM
Mwangaza
250
CR
600:1
Rangi
16.2M
Mwangaza nyuma
CCFL
Kiolesura
LVDS
In Stock
13886
Vipimo

Nambari ya Sehemu QD15XL13 Rev.01
ChapaQDI
Ukubwa15.0
MaombiDMPC
Azimio1024×768
MuundoLCM
Mwangaza250
CR600:1
Rangi16.2M
Mwangaza nyumaCCFL
KiolesuraLVDS
chapa ya paneliQDI
mfano wa paneliQD15XL13 Rev.01
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli15.0 inch
azimio1024(RGB)×768 , XGA
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi304.128×228.096 mm
muhtasari326.5×253.5 mm
usoAntiglare, Hard coating (3H), Antireflection
mwangaza250 cd/m² (Typ.)
uwiano wa utofautishaji600:1 (Typ.)
kuonyesha rangi16.2M (6-bit + FRC)
wakati wa majibu3/13 (Typ.)(Tr/Td)
angle ya kutazama60/60/45/55 (Typ.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taa2 pcsCCFLWithout Driver
kiolesura cha isharaLVDS (1 ch, 8-bit), 20 pins
voltage ya pembejeo3.3V (Typ.)
rohs:
maombiDMPC
