| Nambari ya Sehemu | S039WQ01 |
| Chapa | CDTECH |
| Ukubwa | 3.9 |
| Maombi | Industrial Stretched |
| Azimio | 480×128 |
| Muundo | LCM, a-Si TFT-LCD |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 5S2P |
| Kiolesura | |
| mtengenezaji | CDTECH |
| jina la mfano | S039WQ01 |
| ukubwa wa skrini | 3.9 inch (1/2 cut of 4.3") |
| aina ya skrini | LCM, a-Si TFT-LCD |
| nambari ya pixel | 480(RGB)×128 128PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 95.04 × 25.34 (H×V) |
| muhtasari(mm) | 105.5 × 40.64 × 3.15 (H×V×D) |
| eneo la bezel(mm) | 98.04 × 28.34 (H×V) |
| matibabu | - |
| mwangaza | 500 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500 : 1 (Typ.) (TM) |
| angle ya kutazama | 65/65/55/65 (Typ.)(CR≥10) |
| majibu | 10/15 (Typ.)(Tr/Td) ms |
| mtazamo mzuri | 12 o'clock |
| hali ya kazi | TN, Normally White, Transmissive |
| kina cha rangi | 16.7M 50% NTSC |
| backlight | 5S2P WLED , 30K hours , No Driver |
| wingi | TBD |
| kutumika kwa | Industrial Stretched Bar LCD Automotive Display |
| kiwango cha upya | - |
| skrini ya kugusa | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
