| Nambari ya Sehemu | S046WV01 |
| Chapa | CDTECH |
| Ukubwa | 4.6 |
| Maombi | Industrial |
| Azimio | 800×320 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 6S2P |
| Kiolesura | Parallel |
| chapa ya paneli | CDTECH |
| mfano wa paneli | S046WV01 |
| saizi ya paneli | 4.6" |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 800(RGB)×320, 188PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 108(W)×43.2(H) mm |
| ufunguzi wa bezel | 110.6(W)×46.0(H) mm |
| saizi ya muhtasari | 120.7(W)×56.16(H) ×3.3(D) mm |
| uso | - |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) (TM) |
| angle ya kutazama | 65/65/55/65 (Typ.)(CR≥10) |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| mwonekano bora zaidi | 12 o'clock |
| wakati wa majibu | 20 (Typ.)(Tr+Td) |
| kuonyesha rangi | 16.7M 50% NTSC |
| aina ya taa | 6S2P WLED , 25K hours , Without Driver |
| masafa | 60Hz |
| skrini ya kugusa | Without |
| uzito wa paneli | TBD |
| maombi | Industrial |
| kiolesura cha ishara | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| voltage ya pembejeo | 3.3V (Typ.)(VDD) |
| mazingira | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
