| Nambari ya Sehemu | S050WV49 |
| Chapa | CDTECH |
| Ukubwa | 5.0 |
| Maombi | Automotive Display I |
| Azimio | 800×480 |
| Muundo | LCM, a-Si TFT-LCD |
| Mwangaza | |
| CR | 600:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 6S2P |
| Kiolesura | Parallel |
| mtengenezaji | CDTECH |
| jina la mfano | S050WV49 |
| ukubwa wa skrini | 5.0 inch |
| aina ya skrini | LCM, a-Si TFT-LCD |
| nambari ya pixel | 800(RGB)×480 (WVGA) 188PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 108 × 64.8 (H×V) |
| muhtasari(mm) | 120.7 × 75.8 × 3.2 (H×V×D) |
| eneo la bezel(mm) | 110.6 × 67.6 (H×V) |
| matibabu | - |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 600 : 1 (Typ.) (TM) |
| angle ya kutazama | 65/65/55/65 (Typ.)(CR≥10) |
| majibu | 20/20 (Typ.)(Tr/Td) ms |
| mtazamo mzuri | 12 o'clock |
| hali ya kazi | TN, Normally White, Transmissive |
| kina cha rangi | 16.7M 50% NTSC |
| backlight | 6S2P WLED , 25K hours , No Driver |
| wingi | TBD |
| kutumika kwa | Automotive Display Industrial |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | Parallel RGB (1 ch, 8-bit) , FPC 40 pins |
| usambazaji wa voltage | 3.3/10.4/16.0/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| max. ukadiriaji | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| A050FW03 V2 | AUO | 5.0 | 480×272 |
| ACX534AKM-2 | SONY | 5.0 | 800×600 |
| AMS495QA04 | Samsung | 5.0 | 960×544 |
| AT050TN34 | Innolux | 5.0 | 480×272 |
| AT050TN35 | Innolux | 5.0 | 480×272 |
| HSD050I551-A00 | HannStar | 5.0 | 320×234 |
| LB050WQ2-TD03 | LG Display | 5.0 | 480×272 |
| LH500X01-SD01 | LG Display | 5.0 | 768×1024 |
| LTG500QV-F03 | Samsung | 5.0 | 320×240 |
| PD050VL1 | E Ink | 5.0 | 640×480 |
