| Nambari ya Sehemu | SL3229ML-L1 |
| Chapa | STI |
| Ukubwa | 28.7 |
| Maombi | Stretched Bar LCD Di |
| Azimio | 1366×415 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 1200:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | - |
| Kiolesura | LVDS |
| chapa ya paneli | STI |
| mfano wa paneli | SL3229ML-L1 |
| saizi ya paneli | 28.7" (8/15 cut of 32") |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 1366(RGB)×415, 49PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 697.685(W)×211.961(H) mm |
| ufunguzi wa bezel | - |
| mwangaza | - |
| uwiano wa utofautishaji | 1200:1 (Typ.) (TM) |
| angle ya kutazama | 89/89/89/89 (Min.)(CR≥10) |
| hali ya kuonyesha | IPS, Normally Black, Transmissive |
| mwonekano bora zaidi | Symmetry |
| wakati wa majibu | 8 (Typ.)(G to G) |
| kuonyesha rangi | 16.7M |
| aina ya taa | |
| masafa | 60Hz |
| skrini ya kugusa | Without |
| uzito wa paneli | - |
| maombi | Stretched Bar LCD Digital Signage |
| kiolesura cha ishara | LVDS (1 ch, 8-bit) , 30 pins Connector |
| voltage ya pembejeo | 12.0V (Typ.) |
| mazingira | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
