| Nambari ya Sehemu | T546HB01 V0 |
| Chapa | AUO |
| Ukubwa | 55 |
| Maombi | LCTV |
| Azimio | 1920×1080 |
| Muundo | LCM |
| Mwangaza | 360 |
| CR | 4000:1 |
| Rangi | 16.7M/1.07B |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | AUO |
| mfano wa paneli | T546HB01 V0 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 55 inch |
| azimio | 1920(RGB)×1080 , FHD |
| hali ya kuonyesha | AMVA3, Normally Black, Transmissive |
| eneo la kazi | 1209.6×680.4 mm |
| muhtasari | 1255.6×726.4 mm |
| uso | |
| mwangaza | 360 cd/m² (Typ.) |
| uwiano wa utofautishaji | 4000:1 (Typ.) |
| kuonyesha rangi | 16.7M/1.07B (8-bit / 8-bit + Hi-FRC), CIE193172% |
| wakati wa majibu | 5.5 (Typ.)(G to G) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 120Hz |
| aina ya taa | WLEDEmbedded (LED Driver) |
| kiolesura cha ishara | LVDS (4 ch, 8/10-bit), 92 pins |
| voltage ya pembejeo | 12.0V (Typ.) |
| maombi | LCTV |
