| Nambari ya Sehemu | TCG070WVLPAANN-AN50-S |
| Chapa | Kyocera |
| Ukubwa | 7.0 |
| Maombi | Industrial |
| Azimio | 800×480 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 262K |
| Mwangaza nyuma | 2 |
| Kiolesura | Parallel |
| chapa ya paneli | Kyocera |
| saizi ya paneli | 7.0" |
| azimio | 800(RGB)×480, WVGA, 133PPI |
| eneo la maonyesho | 152.4(W)×91.44(H) mm |
| saizi ya muhtasari | 165(W)×104.4(H) ×8.5(D) mm |
| mwangaza | 900 cd/m² (Typ.) |
| angle ya kutazama | 80/80/60/80 (Typ.)(CR≥10) |
| mwonekano bora zaidi | 12 o'clock |
| kuonyesha rangi | 262K 49% NTSC |
| masafa | - |
| uzito wa paneli | 195g (Typ.) |
| kiolesura cha ishara | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| voltage ya pembejeo | 3.3V (Typ.) |
| mazingira | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| mfano wa paneli | TCG070WVLPAANN-AN50-S |
| aina ya paneli | a-Si TFT-LCD , LCM |
| muundo wa pixel | RGB Vertical Stripe |
| ufunguzi wa bezel | 154.4(W)×93.4(H) mm |
| uso | Antiglare |
| uwiano wa utofautishaji | 1000:1 (Typ.) (TM) |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| wakati wa majibu | 5/25 (Typ.)(Tr/Td) |
| aina ya taa | 2 strings WLED , 50K hours , Without Driver |
| skrini ya kugusa | Without |
| maombi | Industrial |
