| Nambari ya Sehemu | TFT08925601600 |
| Chapa | SEBO |
| Ukubwa | 8.9 |
| Maombi | PAD |
| Azimio | 2560×1600 |
| Muundo | LCM |
| Mwangaza | 500 |
| CR | 1200:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | MIPI |
| chapa ya paneli | SEBO |
| mfano wa paneli | TFT08925601600 2 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 8.9 inch |
| azimio | 2560(RGB)×1600 , WQXGA |
| hali ya kuonyesha | IPS, Normally Black, Transmissive |
| eneo la kazi | 192×120 mm |
| muhtasari | 200.3×132.1×3.43 mm |
| uso | |
| mwangaza | 500 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1200:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193172% |
| wakati wa majibu | |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 6S6PWLEDWithout Driver |
| kiolesura cha ishara | MIPI (2 ch, 4 data lanes), 61 pins |
| voltage ya pembejeo | 1.8/3.3V (Typ.)(VDDIO/VBAT) |
| maombi | PAD |
