| Nambari ya Sehemu | TL055BDXP03 |
| Chapa | TIANMA |
| Ukubwa | 5.5 |
| Maombi | Mobile Phone |
| Azimio | 1440×2560 |
| Muundo | LCM , LTPS TFT-LCD |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 5S3P |
| Kiolesura | MIPI |
| mtengenezaji | TIANMA |
| ukubwa wa skrini | 5.5 inch |
| nambari ya pixel | 1440(RGB)×2560 (Quad-HD) 537PPI |
| eneo amilifu(mm) | 68.04 × 120.96 (H×V) |
| mwangaza | - |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| mtazamo mzuri | Symmetry |
| kina cha rangi | 16.7M 70% NTSC |
| wingi | TBD |
| kiwango cha upya | 70Hz |
| aina ya ishara | MIPI (2 ch, 4 data lanes) , 50 pins Connector |
| usambazaji wa voltage | 1.8/5.5/-5.5V (Typ.)(IOVCC/VSP/VSN) |
| max. ukadiriaji | Storage Temp.: -30 ~ 70 °C Operating Temp.: -30 ~ 60 °C |
| jina la mfano | TL055BDXP03 |
| aina ya skrini | LCM , LTPS TFT-LCD |
| mpangilio | RGB Vertical Stripe |
| muhtasari(mm) | 70.94 × 128.29 × 1.46 (H×V×D) |
| uwiano wa utofautishaji | 800 : 1 (Typ.) (TM) |
| majibu | 8 (Typ.)(Tr+Td) ms |
| hali ya kazi | SFT, Normally Black, Transmissive |
| backlight | 5S3P WLED |
| kutumika kwa | Mobile Phone |
| skrini ya kugusa | Without |
