| Nambari ya Sehemu | TM018FDZ02 |
| Chapa | Tianma |
| Ukubwa | 1.8 |
| Maombi | MPH |
| Azimio | 128×160 |
| Muundo | LCM |
| Mwangaza | 190 |
| CR | 250:1 |
| Rangi | 65K/262K |
| Mwangaza nyuma | WLED |
| Kiolesura | SPI |
| chapa ya paneli | TIANMA |
| mfano wa paneli | TM018FDZ02 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 1.8 inch |
| azimio | 128(RGB)×160 |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 28.032×35.04 mm |
| muhtasari | 34×45.83×2.85 mm |
| uso | |
| mwangaza | 190 cd/m² (Typ.) |
| uwiano wa utofautishaji | 250:1 (Typ.) |
| kuonyesha rangi | 65K/262K , CIE193158% |
| wakati wa majibu | 15/35 (Typ.)(Tr/Td) |
| angle ya kutazama | 65/65/50/65 (Typ.)(CR≥10)(L/R/U/D) |
| aina ya taa | 1S2PWLEDWithout Driver |
| kiolesura cha ishara | SPI, 14 pins |
| voltage ya pembejeo | 2.8/2.8V (Typ.)(VDDI/VDD) |
| maombi | MPH |
| AMS470GS16-1 | Samsung | 4.7 | 720×1280 |
| AMS529BY01 | Samsung | 5.3 | 1080×1920 |
| DLC0350TZG | Other | 3.5 | 240×320 |
| EJ030NC-02A | Innolux | 3.0 | |
| H497TLB01.4 | AUO | 5.0 | 720×1280 |
| H572DAN01.2 | AUO | 5.7 | 1080×1920 |
| LS026Q7UX01 | SHARP | 2.6 | 320×240 |
| LS040T3SW01 | SHARP | 4.0 | 540×960 |
| LS059T1SX01 | SHARP | 5.9 | 1080×1920 |
| TX09D83VM3CEA | KOE | 3.5 | 240×320 |
