| Nambari ya Sehemu | TM028HDZG59 |
| Chapa | TIANMA |
| Ukubwa | 2.8 |
| Maombi | Mobile Phone |
| Azimio | 240×320 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 400:1 |
| Rangi | 65K/262K |
| Mwangaza nyuma | WLED |
| Kiolesura | 16-bit |
| chapa | TIANMA |
| ukubwa wa diagonal | 2.8 inch |
| muundo wa pixel | 240(RGB)×320 [QVGA] 141PPI |
| eneo la kazi | 43.2(H)×57.6(V) mm |
| mwangaza | 300 cd/m² (Typ.) |
| tazama mwelekeo | - |
| angle ya kutazama | 70/70/70/58 (Typ.)(CR≥10) |
| rangi ya msaada | 65K/262K 63% NTSC |
| uzito | TBD |
| kiwango cha fremu | - |
| aina ya kiolesura | 16-bit 8080 parallel , 37 pins FPC |
| usambazaji wa nguvu | 2.7/3.3V (Min./Max.)(VCI/VCC1/VCC2) |
| mazingira | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| mfano | TM028HDZG59 |
| aina | a-Si TFT-LCD , LCM |
| usanidi | RGB Vertical Stripe |
| muhtasari dim. | 50(H)×69.2(V) mm |
| uwiano wa utofautishaji | 400:1 (Typ.) (TM) |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| hali ya uendeshaji | TN, Normally White, Transmissive |
| chanzo cha mwanga | WLED [1S4P] , W/O Driver |
| iliyoundwa kwa ajili ya | Mobile Phone |
| jopo la kugusa | Without |
