| Nambari ya Sehemu | TM030XDHG30 |
| Chapa | TIANMA |
| Ukubwa | 2.1 |
| Maombi | Round Display Instru |
| Azimio | 480×480 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 4S1P |
| Kiolesura | Parallel |
| mtengenezaji | TIANMA |
| jina la mfano | TM030XDHG30 |
| ukubwa wa skrini | 2.1 inch |
| aina ya skrini | LCM , a-Si TFT-LCD |
| nambari ya pixel | 480(RGB)×480 228PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 53.28 × 53.28 (H×V) |
| muhtasari(mm) | 58.01 × 61.38 × 2.65 (H×V×D) |
| eneo la bezel(mm) | - |
| matibabu | Hard coating |
| mwangaza | 450 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800 : 1 (Typ.) (TM) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| majibu | 25 (Typ.)(Tr+Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | SFT, Normally Black, Transmissive |
| kina cha rangi | 16.7M 53% NTSC |
| backlight | 4S1P WLED , No Driver |
| wingi | 16.9g (Typ.) |
| kutumika kwa | Round Display Instruments & Meters |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | Parallel RGB (1 ch, 8-bit) + SPI , 41 pins FPC |
| usambazaji wa voltage | (1.8/2.8)/2.8V (Typ.)(IOVCC/VCC) |
| max. ukadiriaji | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| TM030CDH51-00 | Tianma | 3.0 | 320×240 |
| TM030LBHT1 | Tianma | 3.0 | 240×400 |
| TM030LDHT1 | Tianma | 3.0 | 240×400 |
| TM030LDHT2 | Tianma | 3.0 | 240×400 |
| TM030ZDHG01 | Tianma | 3.0 | 320×320 |
