| Nambari ya Sehemu | TM045YDH27 |
| Chapa | Tianma |
| Ukubwa | 4.5 |
| Maombi | MPH |
| Azimio | 480×854 |
| Muundo | LCM |
| Mwangaza | 280 |
| CR | 500:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | MIPI |
| chapa ya paneli | TIANMA |
| mfano wa paneli | TM045YDH27 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 4.5 inch |
| azimio | 480(RGB)×854 , FWVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 55.44×98.637 mm |
| muhtasari | 60.04×109.1×2.6 mm |
| uso | |
| mwangaza | 280 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193164% |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| angle ya kutazama | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 8S1PWLEDWithout Driver |
| kiolesura cha ishara | MIPI (2 data lanes), 25 pins |
| voltage ya pembejeo | (1.8/2.8)/2.8V (Typ.)(IOVCC/VCC) |
| maombi | MPH |
