| Nambari ya Sehemu | TM060JVZG02 |
| Chapa | TIANMA |
| Ukubwa | 6.0 |
| Maombi | Medical Imaging |
| Azimio | 800×1280 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 8S2P |
| Kiolesura | MIPI |
| mtengenezaji | TIANMA |
| jina la mfano | TM060JVZG02 |
| ukubwa wa skrini | 6.0 inch |
| aina ya skrini | LCM , a-Si TFT-LCD |
| nambari ya pixel | 800(RGB)×1280 (WXGA) 251PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 80.76 × 129.216 (H×V) |
| muhtasari(mm) | 104.16 × 152.62 × 6.5 (H×V×D) |
| eneo la bezel(mm) | - |
| matibabu | Antiglare (Haze 1%) |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800 : 1 (Typ.) (TM) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| majibu | 25 (Typ.)(Tr+Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | SFT, Normally Black, Transmissive |
| kina cha rangi | 16.7M 68% NTSC |
| backlight | 8S2P WLED , 30K hours , No Driver |
| wingi | TBD |
| kutumika kwa | Medical Imaging |
| kiwango cha upya | - |
| skrini ya kugusa | PCAP |
| aina ya ishara | MIPI (4 data lanes) , 45 pins FPC |
| usambazaji wa voltage | 1.8/5.0/-5.0V (Typ.)(VDDI/AVDD/AVEE) |
| max. ukadiriaji | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.0G (19.6 m/s²) |
