| Nambari ya Sehemu | TM080VDSP03 |
| Chapa | TIANMA |
| Ukubwa | 8.0 |
| Maombi | Pad & Tablet |
| Azimio | 1200×1920 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 7S3P |
| Kiolesura | |
| chapa ya paneli | TIANMA |
| saizi ya paneli | 8.0" |
| azimio | 1200(RGB)×1920, WUXGA, 283PPI |
| eneo la maonyesho | 107.64(W)×172.224(H) mm |
| saizi ya muhtasari | 114.58(W)×184.09(H) ×3.95(D) mm |
| mwangaza | 390 cd/m² (Typ.) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| mwonekano bora zaidi | Symmetry |
| kuonyesha rangi | 16.7M 60% NTSC |
| masafa | 60Hz |
| uzito wa paneli | TBD |
| voltage ya pembejeo | 3.3V (Typ.)(VCI) |
| mazingira | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -15 ~ 70 °C |
| mfano wa paneli | TM080VDSP03 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| muundo wa pixel | RGB Vertical Stripe |
| ufunguzi wa bezel | - |
| uso | Hard coating |
| uwiano wa utofautishaji | 800:1 (Typ.) (TM) |
| hali ya kuonyesha | SFT, Normally Black, Transmissive |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| aina ya taa | 7S3P WLED |
| skrini ya kugusa | Without |
| maombi | Pad & Tablet |
